Q. A 2 m × 4 m rectangular footing has to carry a uniformly distributed load of 120 kPa. As per the 2:1 dispersion method of stress distribution, the increment in vertical stress (in kPa) at a depth of 2 m below the footing is

Solution:

Increment in the vertical stress

=120×2×4/(2+h)(4+h)

=120×2×4/(2+2)(4+2)

= 40 kPa
