Q. A parabolic vertical curve is being designed to join a road of grade +5% with a road of grade -3%. The length of the vertical curve is 400 m measured along the horizontal. The vertical point of curvature (VPC) is located on the road of grade +5%. The difference in height between VPC and vertical point of intersection (VPI) (in m, round off to the nearest integer) is

Solution:

n1=0.05

n2=−0.03

L=400 m

The difference in the height between VPC and VPI,

y=n1×L/2

=0.05×400/2

=10 m
