As shown in the figure, temperature q is measured using a K type thermocouple

As shown in the figure, temperature q is measured using a K type thermocouple

Q. As shown in the figure, temperature q is measured using a K type thermocouple. It has a sensitivity of 40 mV/°C. The gain (G) of the ideal instrumentation amplifier is 25. If the output Vo is 96 mV, then the value of q (in °C) is _ .

Ans: 95-97

gate questions
