Q. For an LTI system, the Bode plot for its gain is as illustrated in the figure shown. The number of system poles 𝑁_𝑝 and the number of system zeros 𝑁_𝑧 in the frequency range 1 Hz ≤ 𝑓 ≤ 10⁷ Hz is

(A) 𝑁_𝑝 = 5, 𝑁_𝑧 = 2

(B) 𝑁_𝑝 = 6, 𝑁_𝑧 = 3

(C) 𝑁_𝑝 = 7, 𝑁_𝑧 = 4

(D) 𝑁_𝑝 = 4, 𝑁_𝑧 = 2

Ans: Np = 6, Nz = 3
