Q. Four bolts P, Q, R and S of equal diameter are used for a bracket subjected to a load of 130 kN as shown in the figure.

The force in bolt P is

(A) 32.50 kN              (B) 69.32 kN              (C) 82.50 kN              (D) 119.32 kN

Ans: 69.32 kN
