In the circuit shown below, a positive edge-triggered D Flip-Flop is used for sampling input data

Q. In the circuit shown below, a positive edge-triggered D Flip-Flop is used for sampling input data 𝐷_𝑖𝑛 using clock 𝐶𝐾. The XOR gate outputs 3.3 volts for logic HIGH and 0 volts for logic LOW levels. The data bit and clock periods are equal and the value of Δ𝑇/𝑇_𝐶𝐾 = 0.15, where the parameters Δ𝑇 and 𝑇_𝐶𝐾 are shown in the figure. Assume that the Flip-Flop and the XOR gate are ideal.

If the probability of input data bit (𝐷_𝑖𝑛) transition in each clock period is 0.3, the average value (in volts, accurate to two decimal places) of the voltage at node 𝑋, is

Ans: 0.82 – 0.86
