What is the minimum number of 2-input NOR gates required to implement a 4-variable function expressed in sum-of-minterms form as f = Σ (0, 2, 5, 7, 8, 10, 13, 15)?

Q. What is the minimum number of 2-input NOR gates required to implement a 4-variable function expressed in sum-of-minterms form as f = Σ (0, 2, 5, 7, 8, 10, 13, 15)? Assume that all the inputs and their complements are available. Answer:                                                     .

Ans:

K-map for given,

f = Σ(0, 2, 5, 7, 8, 10, 13, 15)

Therefore,

f = BD +B’D’

= (B’ + D).(B + D’)

Since all the inputs and their complements are available, so circuit implementation using NOR gate:

F can be implemented using 3 NOR gates.

So, option (A) is correct.
