Q. Block P of mass 2 kg slides down the surface and has a speed 20 m/s at the lowest point, Q, where the local radius of curvature is 2 m as shown in the figure. Assuming g = 10 m/s2, the normal force (in N) at Q is_____________________(correct to two decimal places). Ans: 419.00 […]
Block P of mass 2 kg slides down the surface and has a speed 20 m/s at the lowest Read More »
Q. The schematic of an external drum rotating clockwise engaging with a short shoe is shown in the figure. The shoe is mounted at point Y on a rigid lever XYZ hinged at point X. A force 𝐹 = 100 𝑁 is applied at the free end of the lever as shown. Given that the
Q. Processing times (including setup times) and due dates for six jobs waiting to be processed at a work centre are given in the table. The average tardiness (in days) using shortest processing time rule is____________________(correct to two decimal places). Job Processing time (days) Due date (days) A 3 8 B 7 16 C 4
Q. The minimum value of 3𝑥 + 5𝑦 such that: 3𝑥 + 5𝑦 ≤ 15 4𝑥 + 9𝑦 ≤ 8 13𝑥 + 2𝑦 ≤ 2 𝑥 ≥ 0, 𝑦 ≥ 0 is_________________. Ans: 0
The minimum value of 3𝑥 + 5𝑦 such that Read More »
Q. A bar is compressed to half of its original length. The magnitude of true strain produced in the deformed bar is_____________(correct to two decimal places). Ans:
Q. An orthogonal cutting operation is being carried out in which uncut thickness is 0.010 mm, cutting speed is 130 m/min, rake angle is 15° and width of cut is 6 mm. It is observed that the chip thickness is 0.015 mm, the cutting force is 60 N and the thrust force is 25 N.
Q. The true stress (σ) – true strain ( e ) diagram of a strain hardening material is shown in figure. First, there is loading up to point A, i.e., up to stress of 500 MPa and strain of 0.5. Then from point A, there is unloading up to point B, i.e., to stress of
Q. A plane slab of thickness L and thermal conductivity k is heated with a fluid on one side (P), and the other side (Q) is maintained at a constant temperature, TQ of 25°C, as shown in the figure. The fluid is at 45°C and the surface heat transfer coefficient, h, is 10 W/m2K .
Q. An engine working on air standard Otto cycle is supplied with air at 0.1 MPa and 35°C. The compression ratio is 8. The heat supplied is 500 kJ/kg. Property data for air: cp = 1.005 kJ/kg K, cv = 0.718 kJ/kg K, R = 0.287 kJ/kg K. The maximum temperature (in K) of the
An engine working on air standard Otto cycle is supplied with air at 0.1 MPa and 35°C Read More »
Q. Steam flows through a nozzle at a mass flow rate of m = 0.1kg/s with a heat loss of 5 kW. The enthalpies at inlet and exit are 2500kJ/kg and 2350 kJ/kg, respectively. Assuming negligible velocity at inlet ( C1 » 0 ), the velocity ( C2 ) of steam (in m/s) at the nozzle
